Our committment to excellence

Our goal is to always provide our customers with the finest printed circuit boards in the market today. With that in mind we are always re-investing in our facility making sure that we have the best equipment available to us today.



During the past 18 months we have invested over $3 million in state-of-the-art equipment including:

  • Microcraft Emma E4L6151 Flying probe electrical test machine
  • CAMTEK Phoenix -HDI AOI system
  • OLEC ACCUTRAY AT-30 High resolution Printer Exposing unit
  • STRUERS Abramin Cross section Machine
  • Perkin Elmer Pinnacle 500 AA spectrometer
  • CHEMCUT XLI strip, etch, tin strip line
  • Circuit Automation DP2500 LPI Screening machine
  • Precision Quincy Tunnel ovens
  • Accusytems Accu Score AS-150-MAX scoring machine
  • MANIFOLD PLATING EQUIPMENT LTD Auto Desmear& PTH
  • MANIFOLD PLATING EQUIPMENT LTD Auto Pattern Plating

OUR PROCESS

What makes us stand out above the rest

PRECISION DRILLING

Our state-of-the -art computer controlled, highly accurate high speed drillers, with built in TMG (Tool Metrology Gauge) for laser diameter checks, spindle radial run-out verification and drill breakage detection, we can drill finished via holes as small as 5 mils (with extreme accuracy) to read within ±.001 mils. allowing us to meet the most demanding drilling and fabricating specifications.

PHOTO IMAGING

Our carefully controlled, environmentally clean photo-imaging area and automated aligning high resolution imaging units ensures that line width and spacing are printed accurately down to 2 and 2.

PLATING LINES

To ensure consistency and the highest quality, our chemical engineers closely control the process. Daily analysis and System Process Control (SPC) charting help maintain the highest quality and complete traceability. Our state of the art, FULLY AUTOMATED electroless plating line utilizing the latest technology with ensure the top quality reliable copper plating even on the finest hole diameters. Our AUTOMATED pattern plating line ensures the top quality copper plating with utilizing the latest dual rectifier technology.

ETCHING

With our newest SES ( strip–etch– strip ) line we can etch width and spacing down to 3 and 3 with extreme accuracy and up to 10 ounce copper.

AOI

Using our latest AOI technology, we are able to detect any defects prior to the solder mask and lamination cycle to prevent any repairs after the solder-mask application.

SOLDER MASK

Our automated LPI coating equipment applies the solder mask consistently and efficiently.

SCORING

We are utilizing the advanced scoring technology, and are able to hold tight tolerances with extreme accuracy and flexibility, including metal core boards.

ELECTRICAL TESTING

Our state of the art testing facility allows testing of ALL PCBs efficiently and economically. To ensure that the boards meet all of the net list requirements, we electrically test 100% of our boards. This will guarantee that each circuit board meets the functional requirements of the board. We also have clam shell fixture testing capabilities.

To receive FREE SAMPLE connect with us by calling us - Phone(847) 806-7777 | Fax (847) 806-8088
